HP12832-04

Small OLED 0.91 inch 128×32 with SSD1306 oled screen

Keyword

Our Services

♦ As a manufacturer, our products are cost-effective.

♦ Over 11 years experience of business sales,installation and service.

♦ Professional design and installation teams give you the best solution to help you take orders or maximize screen value.

♦ We offer adequate technical support and our senior engineers will make sure the screen running well.In addition, they can also teach your colleagues how to use the screen.

♦ There is always a flexible payment method which is your favorite.

♦ The dedicated after-sales service department responds to your questions in the first time and gives you the perfect solution to your problems.

CONTACT NOW

Product Description
Mechanical Diagram
Production Advantages

Product Description

Module No.:	HP12832-04-TSWG15P091
Structure:	COG
Screen Size:	0.91 inch
Number of Dots:	128 x 32
Color:	Monochrome (White)
Module Size:	30.0 x 11.50 x 1.227 mm
Viewing Area:	24.384 x 7.584 mm
Active Area:	22.384 x 5.584 mm
Driver IC:	SSD1306BZ
Interface:	4-wire SPI
Connector:	FPC
Pin Number:	15
Operating Temperature:	-40～+70℃
Storage Temperature:	-40～+85℃

Interface Pin Description

PIN	SYMBOL	PIN	SYMBOL	PIN	SYMBOL	PIN	SYMBOL
1	C2P	5	VBAT	9	RES#	13	IREF
2	C2N	6	VSS	10	D/C#	14	VCOMH
3	C1P	7	VDD	11	SCLK	15	VCC
4	C1N	8	CS#	12	SDIN

Mechanical Diagram

small OLED 0.91 inch 128x32 with SSD1306 oled screen (2)
