TFT445B001

4.45” 480X272 WQVGA IPS TFT LCD with 40pin RGB

Keyword

Product description

● TFT445B001: 4.45 inch IPS TFT LCD

● Resolution: 480xRGBx854

● Outline dimension: 60(H)x109(V)x2.15 D mm

● Active area: 55.44×98.38 mm

● Driver IC: GC9503CV

● Display Mode: Normally Black

● Number of Colors:16.7M

● Viewing Direction: Free

● Contrast Ratio: 1200

● Luminance: 350cd/m2 Typ.

● Light Source: 10 LED light

● Interface: 40 pin MIPI

● Operating Temperature: -20~+70 ℃

● Storage Temperature: -30~+80 ℃

CONTACT NOW

Product Description
Mechanical Diagram
Production Advantages

Product Description

No.	Item	Specification	Unit
1	LCD Size	4.45	inch
2	Panel Type	IPS	-
3	Resolution	480xRGBx854	Pixel
4	Display Mode	Normally BLACK	-
5	Number of Colors	16.7M
6	Viewing Direction	ALL	-
7	NTSC	50%	Typ.
8	Contrast Ratio	1200
9	Luminance	350	cd/m2
10	Module Size	60(H)x109(V)x2.15 D	mm
11	Panel Active Area	55.44×98.38	mm
12	Driver IC	GC9503CV
13	Light Source	10 LEDS light
14	Interface	40 PIN MIPI
15	Operating Temperature	-20~+70
16	Storage Temperature	-30~+80

Detail Description

The TFT445B001 is a 4.45 inch IPS TFT LCD display module with a resolution of 480xRGBx854. The outline dimension of the module is measured at 60(H)x109(V)x2.15D mm, while the active area of the display is 55.44×98.38 mm.The driver IC used in the module is GC9503CV and it operates in normally black display mode.

The display can be viewed from any direction without any restriction and it supports 16.7 million colors. The module has a high contrast ratio of 1200 and a typical luminance of 350cd/m2.It employs 10 LED lights as the light source and utilizes a 40 pin MIPI interface.

Mechanical Diagram

4.45” 480X272 WQVGA IPS TFT LCD with 40pin RGB (2)

Why Choose Us?

1. We are professional LCD module manufacture in China with precise and advanced equipment.
2. More than 12 years of industry experience and involved main markets all over the world.
3. We have well-trained and professional sales team will offer you 24 hours online and immediate service.
4. We offer 12 months warranty for all of our product.
5. We can provide customized services, ect.

Wanna learn more about this 4.45 inch IPS TFT LCD? Contact us.
