HP12832-05

0.91″ 128×32 White color OLED Display for e-cigirite

Keyword

Contact us:

Lyna Huang

WhatsApp: 0086-13632586591

Skype: lynahuang2012

E-mail: sales@huaxianjing.com

CONTACT NOW

Product Description
Mechanical Diagram
Production Advantages

Product Description

Module No.:	HP12832-05-TSWG14P087
Structure:	COG
Screen Size:	0.87 inch
Number of Dots:	128 x 32
Color:	Monochrome (White)
Module Size:	29.00 x 8.7 x 1.22 mm
Viewing Area:	22.856 x 6.824 mm
Active Area:	21.356 x 5.324 mm
Driver IC:	SSD1316Z
Interface:	I2C
Connector:	FPC
Pin Number:	14
Operating Temperature:	-40～+70℃
Storage Temperature:	-40～+85℃

Interface Pin Description

PIN	SYMBOL	PIN	SYMBOL	PIN	SYMBOL	PIN	SYMBOL
1	C2P	5	VBAT	9	RES#	13	VCOMH
2	C2N	6	NC	10	SCL	14	VCC
3	C1P	7	VSS	11	SDA
4	C1N	8	VDD	12	IREF

Mechanical Diagram

0.91 128x32 White color OLED Display for e-cigirite-01 (1)

More other product: segment lcd display

0.91 128x32 White color OLED Display for e-cigirite-01 (2)

FAQ

1. Q: How can I get the samples? Standard sample and Custom.

A: Custom sample : send inquiry → offer quotation → confirm quotation & pay tooling charge → provide drawing → confirm drawing → make tooling & samples → samples finished → delivery via express.

2.Q: How long can I expect to get the sample?

A: Standard sample: 3 work days after confirming the order.

Custom sample: 5-20 days after you confirm our drawing.

3.Q: Can you design the LCD in accordance with our demand?

A: Yes,we will give you the best tooling charge.

4. Q: What is the warranty?

A: One year Warranty.

5.Q:How to place orders ?

A:If you confirm samples ok,please send us your purchase order by Email, then we will send you an Invoice for deposit payment.We need to know the following information of your order.

1)Product information-Quantity,part number.

2)Delivery time required.

3)Shipping information-Company name,address,Phone,Destination sea port.

4)Forwarder's contact details if you have any in China.

Production Advantages

1.High quality. Perfect quality management system, stable quality of raw materials, product quality rate of 98% or more
2.On-time delivery. Ensure that orders are delivered on time and in quantity
3.Full supply chain resources. High demand of raw materials, quality assurance of brand suppliers, perfect management system, ensuring the demand of raw material supply;
4.Constantly optimized manufacturing cost. High degree of automation of production line, comprehensively improve per capita work efficiency, stable product quality, and significantly reduce enterprise production and manufacturing costs; to achieve win-win and value-added mutual enjoyment with customers and employees.
